MS-BJ920N
PRODUCT DESCRIPTION
* Single Seal Configuration
* Balanced Design
* Independent of direction of rotation
* For Plain Shafts
* Rotary unit with encapsulated spring design
TECHNICAL FEATURES
* Compact design with rugged construction
* Capable of withstanding high pressure
* O-Ring is dynamically loaded to present shaft damage
* Can handle media with solid content and viscous media
* Can handle sterile and vacuum application
* Springs are product protected to avoid contamination
EQUIVALENT TO
Temperature: -50°C to +220°C
Pressure: p₁ = 25 bar (363 PSI)
Speed: 20m/s (66ft/s)
MATERIALS AVAILABLE
Seal Face: SiC, TC, Carbon or A-Carbon
Stationary Seat: Carbon, SiC or TC
Elastomers: Viton, Aflas or EPDM
Metal Parts: 304SS
STATIONARY SEATS
Standard Seat: G16
Alternative Seat: G60
HJ92N
HJ977GN
M010
Type 40L
Type 40S
PERFORMANCE CAPABILITIES
